Vibration in steering wheel and gas pedal after 3" READY LIFT install??

Discussion in 'Suspension' started by HILLBILLIE, Sep 16, 2010.

  1. Sep 16, 2010 at 12:17 PM
    #1
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate
    Hey, I just put a 3" READY LIFT (P/N 69-5055) suspension kit in my 2008 Tacoma TRD Off Road. Everything went in great, and had an alighnment done also. Anyways, driving down the road at about 40-60 km/hr I'm experiencing a vibration through my steering wheel, and gas pedal. It feels like I'm driving a truck with a real heavy lug tire, but still havethe stock wheels and tires on. As I reach higher speeds, the vibration seems to get better. I know somebody has an answer to this problem, so for know, I will be on hold waiting for replys.

    Thanks.

  2. Sep 16, 2010 at 12:23 PM
    #2
    RecklessTaco

    RecklessTaco Livin the Dream

    Joined:
    Sep 4, 2009
    Member:
    #22290
    Messages:
    5,145
    Gender:
    Male
    First Name:
    Matt
    Wellington, NV.
    Vehicle:
    08 Dbl Cab Prerunner TRD Sport Debadged
    ENGAGE LT KIT, King 2.5x 8" coilovers w/600lb 18"coil springs, a custom built leaf pack in the rear by OMD, and a custom built prerunner bumper by SurfInferno. 33x12.50-17General Grabbers on 17x9 Black RBP 93R rims, Volant CAI w/Amsoil dry filter, Volant Ram Air, Poweraid Throttle body spacer, URD MAF Calibrator, Flowmaster40, Uniden Bearcat cb w/ 4' fire fly firestick antenna, & a Icom V80 Handheld(Modded for race channels)
    I also have a 08 doublecab and i experienced the same thing. Check the Carrier bearing! when we do not so good things to our trucks like spacer lifts, we forget to by the OME Carrier bearing drop kit! Thats what went out on mine when i was feeling the same pedal vibrations and steering!

  3. Sep 16, 2010 at 12:25 PM
    #3
    Dark Knight

    Dark Knight Well-Known Member

    Joined:
    Jul 18, 2008
    Member:
    #8006
    Messages:
    9,594
    Gender:
    Male
    First Name:
    Jeff
    NC/SC
    Vehicle:
    4Runner Trail
    do you have the Stock UCA's? alignment will still be out of spec with a 3" lift and stock uca's.

  4. Sep 16, 2010 at 12:41 PM
    #4
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate

    Yes I still have the stock carrier bearing. READY LIFT does not specify at all to drop the drive shaft with the 3" Lift.

  5. Sep 16, 2010 at 12:44 PM
    #5
    RecklessTaco

    RecklessTaco Livin the Dream

    Joined:
    Sep 4, 2009
    Member:
    #22290
    Messages:
    5,145
    Gender:
    Male
    First Name:
    Matt
    Wellington, NV.
    Vehicle:
    08 Dbl Cab Prerunner TRD Sport Debadged
    ENGAGE LT KIT, King 2.5x 8" coilovers w/600lb 18"coil springs, a custom built leaf pack in the rear by OMD, and a custom built prerunner bumper by SurfInferno. 33x12.50-17General Grabbers on 17x9 Black RBP 93R rims, Volant CAI w/Amsoil dry filter, Volant Ram Air, Poweraid Throttle body spacer, URD MAF Calibrator, Flowmaster40, Uniden Bearcat cb w/ 4' fire fly firestick antenna, & a Icom V80 Handheld(Modded for race channels)
    Not totally true!:eek: I have stock UCA's And i get mine alligned just fine no Vibrations or pulling or anything like that! Check the Carrier Bearing! Please and let me know if it was bad or not?:D

  6. Sep 16, 2010 at 12:44 PM
    #6
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate

    Yes I still have the stock UCA's. If this does not allow for stock alighnment with the 3" lift, then who has the specs to do the proper alighnment??

  7. Sep 16, 2010 at 12:46 PM
    #7
    RecklessTaco

    RecklessTaco Livin the Dream

    Joined:
    Sep 4, 2009
    Member:
    #22290
    Messages:
    5,145
    Gender:
    Male
    First Name:
    Matt
    Wellington, NV.
    Vehicle:
    08 Dbl Cab Prerunner TRD Sport Debadged
    ENGAGE LT KIT, King 2.5x 8" coilovers w/600lb 18"coil springs, a custom built leaf pack in the rear by OMD, and a custom built prerunner bumper by SurfInferno. 33x12.50-17General Grabbers on 17x9 Black RBP 93R rims, Volant CAI w/Amsoil dry filter, Volant Ram Air, Poweraid Throttle body spacer, URD MAF Calibrator, Flowmaster40, Uniden Bearcat cb w/ 4' fire fly firestick antenna, & a Icom V80 Handheld(Modded for race channels)
    Nobody does! Except for OME!:D

  8. Sep 16, 2010 at 12:47 PM
    #8
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate
    I'm expecting it is good. I just put the lift in this morning, and drove it down the road a couple km, and this is what I'm experiencing. I really have no time on the truck with the lift installed for the carrier bearing to be worn, or bad... I don't think ??

  9. Sep 16, 2010 at 1:11 PM
    #9
    Dark Knight

    Dark Knight Well-Known Member

    Joined:
    Jul 18, 2008
    Member:
    #8006
    Messages:
    9,594
    Gender:
    Male
    First Name:
    Jeff
    NC/SC
    Vehicle:
    4Runner Trail
    any proper alignment shop will have the specs saved in their alignment program. They will be able to give you a print out of current specs before and after the adjustments. on this print out will be the factory alignment specs, most read green numbers if it good, red if its out.

    Ask for this print out every time!

  10. Oct 1, 2010 at 2:11 PM
    #10
    NC15TRD

    NC15TRD Well-Known Member

    Joined:
    Sep 14, 2010
    Member:
    #43212
    Messages:
    6,283
    Gender:
    Male
    First Name:
    Nick
    PA
    Vehicle:
    16 Silverado Z71
    Stock
    Same lift and shake, man. Had alignment done week after install had shake as soon as I got done installing. Putting in carrier bearing drop hopefully tonight, will give you follow up.

  11. Oct 1, 2010 at 3:42 PM
    #11
    bjmoose

    bjmoose Bullwinkle J. Moose

    Joined:
    Aug 31, 2010
    Member:
    #42529
    Messages:
    6,000
    Gender:
    Male
    First Name:
    Steve
    San Jose CA
    Vehicle:
    '11 Std Cab 4x4 5sp
    OME suspension, ARB Air Lockers, CBI/Relentless/Pelfrey armor, HAM radio
    If you lift and put on tires at the same time - there's no way for sure to know if you've got a wheel balance issue or a driveline vibration. That's why it's best to change one parameter at a time.

    These are the best articles I've found on diagnosing/preventing/solving driveline vibration:

    http://www.4crawler.com/4x4/CheapTri...line-101.shtml

    http://www2.dana.com/pdf/J3311-1-HVTSS.PDF

    The *really* short answer is you get under the truck with a tape measure calibrated in 1/16" inch increments, and measure the length of the top of the driveshaft flange to flange, and also the bottom. They should be the same, or the bottom should be 1/16" longer. Use a small CB drop or angled shims between the leaf pack and the axle to correct.

  12. Oct 26, 2010 at 8:32 AM
    #12
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate
    I had my original tires and wheels on the truck during and after the install, and had the vibration/humming noise coming from the truck emediately after. The next day, I had new wheels(Factory 17") and tires, which were balanced and alighned at my local Toyota dealership. Same problem exists.

  13. Oct 26, 2010 at 8:35 AM
    #13
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate
    I have also just received my Old Man Emu carrier bearing shim kit. I installed the spacers, and this problem is not any better. If anything, it may be a little worse.

  14. Oct 26, 2010 at 8:36 AM
    #14
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate
    I odered the O.M.E. carrier bearing kit, insatlled it, and this has not fixed the problem at all.

  15. Oct 26, 2010 at 8:40 AM
    #15
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate

    Had 2 alighnments and wheels balanced 2 times at the Toyota dealership. All was in the green.

  16. Oct 26, 2010 at 7:38 PM
    #16
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate


    All was in the green, what more can you do

  17. Oct 27, 2010 at 3:05 PM
    #17
    toyo freak

    toyo freak Another Toyota Enthusiast

    Joined:
    Mar 7, 2010
    Member:
    #32745
    Messages:
    1,508
    Gender:
    Male
    First Name:
    David
    Mobile, Alabama
    Vehicle:
    2010 V6 D-Cab 4x4
    5100s at 2.5, Wheeler 3 leaf progressive AAL, Weathertech liners, yellow wire mod, toyota OEM bed mat, cup holder mod, afe pro dry s air filter, UWS low pro toolbox, Escort radar detector
    Call readylift and bitch them out. Tell them you had it professionally installed and was guaranteed factory ride

  18. Oct 28, 2010 at 2:24 PM
    #18
    Coolidge

    Coolidge Well-Known Member

    Joined:
    Mar 9, 2010
    Member:
    #32873
    Messages:
    332
    Gender:
    Male
    First Name:
    Guy
    Lancaster, Ca
    Vehicle:
    2003 Pre Runner
    King coilovers frt +3". Bilstein 5100 shocks rear w/AAL, K&N FIPK, Magnablow exhaust, Billet grill, clear corner lights, Sony stereo, JBL, Sub etc.
    Some shops will do a "Visine align" settings enough to "get the red out" Usually caster is tough to get back to stock specs after a lift. But I have a Gen 1, so what do I know?

  19. Oct 28, 2010 at 8:10 PM
    #19
    HILLBILLIE

    HILLBILLIE [OP] Member

    Joined:
    Apr 16, 2010
    Member:
    #35411
    Messages:
    17
    Gender:
    Male
    Halifax
    Vehicle:
    08 Tacoma TRD
    TRD Exhaust, Hood Scoop, Skid Plate
