What Have You Done To Your 2nd Gen Tacoma Today?

Discussion in '2nd Gen. Tacomas (2005-2015)' started by kwalton, Feb 2, 2008.

  1. Dec 13, 2020 at 9:47 PM
    airmax233

    airmax233 Always ready for the next adventure

    Joined:
    Mar 5, 2013
    Member:
    #99098
    Messages:
    1,192
    Gender:
    Male
    Southern California
    Vehicle:
    12 PreRunner SR5 Trd sport & 00 4runner lmtd
    OME 887x coils with 90021 sport struts. Total Chaos Upper control arms. IG: silver_runner23
    Last edited: Dec 13, 2020
  2. Dec 13, 2020 at 10:44 PM
    Hippiglass

    Hippiglass Well-Known Member

    Joined:
    Dec 22, 2014
    Member:
    #144768
    Messages:
    433
    Gender:
    Male
    riverside ca
    Vehicle:
    2012 tacoma sport DCSB
    DTF race kit, DTF front bumper, king 10"dual rate shocks, URD CAI, total chaos upper control arm brackets, method race wheels, 35/12.5/17 bfg ko2, mcneil TT bedsides, custom SLX Motorsports front fenders, fox bump stops
    lol they were only upside down cause the speaker wire that was there didnt reach lol.. routed all new wires for the whole system so its right side up now lol

    GonzoQuick and AStinkyBumb like this.
  3. Dec 14, 2020 at 12:46 AM
    tacotunner06

    tacotunner06 Well-Known Member

    Joined:
    Sep 2, 2017
    Member:
    #228857
    Messages:
    1,027
    Gender:
    Male
    First Name:
    Chris
    Snohomish, Washington
    Vehicle:
    2006 White Tacoma
    LS Swap with RSG Tranzilla, Custom hi clearance front bumper, Relentless: Slider's, bed rails, rear bumper, Prinsu with 40" BD s8. Dirt Designs 3.5 LT. Archive Garage rear towers/shackle flip/SUA. King Air bumps. King LT Coilovers in front. King 12x2.5 in rear. ARB rear air locker and twin compressor. SCS f5's with 33" Ridge Grapplers. 20" S8 mounted in bumper, squadron sport fog lights, squadron pro backup lights, LP6's bumper mounted.
    Mounted my battery boxes and battery switch. then started getting my wires routed.

    Last edited: Dec 14, 2020
    CGoss, 13txtaco, fatfurious2 and 10 others like this.
  4. Dec 14, 2020 at 1:19 AM
    JStiner

    JStiner Well-Known Member

    Joined:
    Mar 22, 2016
    Member:
    #181998
    Messages:
    190
    Gender:
    Male
    First Name:
    Jason
    Vehicle:
    11 MGM 4x4 4.0 double cab
    KO2s (32s) with 2inch level
    No kidding, I just call them?

    Beauxdon likes this.
  5. Dec 14, 2020 at 4:46 AM
    dborrer

    dborrer Well-Known Member

    Joined:
    Apr 28, 2018
    Member:
    #251944
    Messages:
    376
    Gender:
    Male
    First Name:
    Mr. Dan
    St. Augustine, FL
    Vehicle:
    2006 Tacoma TRD Sport 4x MT
    2018 Frame, stock LCAs. SPC (LR) UCAs, Bilstein 5100s front and rear, OME 883 at 0, HeadStrongOffRoad 3 leaf progressive AAL, MESO custom (Red) LED dome, LED Ultimate Maps, Spyder Halo Projector w LEDs, Spyder LED tails
    my belt started to squeal upon start up last week during the cold spell we had.... I just started to research this.... what pulley's did you go with? Were you able to determine that the belt tightener was okay and just the pulley was bad?

  6. Dec 14, 2020 at 4:49 AM
    dborrer

    dborrer Well-Known Member

    Joined:
    Apr 28, 2018
    Member:
    #251944
    Messages:
    376
    Gender:
    Male
    First Name:
    Mr. Dan
    St. Augustine, FL
    Vehicle:
    2006 Tacoma TRD Sport 4x MT
    2018 Frame, stock LCAs. SPC (LR) UCAs, Bilstein 5100s front and rear, OME 883 at 0, HeadStrongOffRoad 3 leaf progressive AAL, MESO custom (Red) LED dome, LED Ultimate Maps, Spyder Halo Projector w LEDs, Spyder LED tails
    Seeing the uv faded cab edges, I had to do a double take because I thought that was my truck for a moment.... Ha! (I just had my cab re-painted recently and it looks like new again...) nice rig!

    Strictlytoyz likes this.
  7. Dec 14, 2020 at 5:42 AM
    Matt

    Matt Active Member

    Joined:
    Dec 23, 2013
    Member:
    #119085
    Messages:
    38
    Gender:
    Male
    Vehicle:
    PreRunner 2011
    [​IMG]
    TRD trailer hitch
    [​IMG]
    TRD oil cap to match the TRO intake

  8. Dec 14, 2020 at 6:13 AM
    deanosaurus

    deanosaurus Caveman

    Joined:
    Jul 23, 2018
    Member:
    #260241
    Messages:
    305
    Northeast Region
    Vehicle:
    09 TRD OR AC
    I went with Gates pulleys from @RockAuto and was pleased with the quality. The parts were made in Canada and had good name brand dual-shielded bearings in them. I used
    If you're replacing one, might as well replace them all, and as far as the tension arm being bad, it's relatively rare for the actual arm to go bad as opposed to just the pulley.

    In my case, I checked before ordering by getting under the truck with a 14mm socket on a short breaker bar and torqueing counter-clockwise on the idler pulley bolt to check the strength of the arm, and it was fine. It took two hands (at an awkward angle) to fully exercise the tensioner. I have no idea what the scientific numbers are for that, but I was satisfied that the actual arm was A-OK.

    Beware that the tension arm idler pulley goes on with reverse threads, and also that the GATES 36174 has slightly different dimensions that the OEM tension arm idler pulley. You can source a longer reverse thread bolt if you want, but I (and many others) simply ended up taking the bushing that comes with the GATES 36174 and putting it into the front of the pulley, then re-using the factory bolt. This will center the bolt in the pulley bore correctly, and the factory tension arm mount point has a mating surface that meets the rear face of the bearing correctly for a mechanically sound mount.

    Since the bearing is shielded on the back, it is not of serious concern to not use the supplied dust shield. If you do try to use it, or to put the bore spacer on the back, it moves the pulley farther forward than the OEM part relative to the path of the belt, which may cause issues with the edge of the belt running off the back of the pulley.

    Torqueing it to the correct value was a bit of a pain since my torque wrench wouldn't fit in order to tighten to spec (since the threads are reversed and the tensioner moves clockwise, you're fighting against the travel of the tensioner while tightening), so I tightened with a socket just until the tensioner started moving CCW and then checked in "reverse" (CW) with the torque wrench. It took two tries to get it within 1 lb of spec, and I called that good.

  9. Dec 14, 2020 at 6:30 AM
    Pizzasteve5717

    Pizzasteve5717 Well-Known Member

    Joined:
    Jan 7, 2019
    Member:
    #278422
    Messages:
    1,321
    Gender:
    Male
    First Name:
    Steven
    Marietta, GA
    Vehicle:
    2005 Tacoma TRD prerunner
    Dude that welder is fye I have the same one you’re gonna like messing around with that thing I’ve built all my armor on my truck with it :thumbsup:

    GonzoQuick and Kuntrykid like this.
  10. Dec 14, 2020 at 6:59 AM
    voilesj11

    voilesj11 Member

    Joined:
    Apr 19, 2020
    Member:
    #325264
    Messages:
    11
    Gender:
    Male
    DG92071 likes this.
  11. Dec 14, 2020 at 7:14 AM
    DG92071

    DG92071 Well-Known Member

    Joined:
    Nov 29, 2019
    Member:
    #312004
    Messages:
    2,524
    anonymouse and theolee like this.
  12. Dec 14, 2020 at 7:35 AM
    mmarrrnold

    mmarrrnold Well-Known Member

    Joined:
    Jan 18, 2014
    Member:
    #120936
    Messages:
    77
    Gender:
    Male
    First Name:
    Matt
    Oceanside, CA
    Vehicle:
    2015 TRD Offroad DCSB
    SCS Ray 10s - Brushed Copper 285/70/17 Nitto Ridge Grapplers Icon 2.5 Coilovers + JBA UCAs Dakar Leafs + OME Nitros Relentless Fab Rear Bumper Some lights
    After a long weekend, here she is.8373F64A-77EB-4BCB-A26C-AADD4A45685D.jpg

  13. Dec 14, 2020 at 7:37 AM
    barlowrs

    barlowrs Well-Known Member

    Joined:
    Feb 12, 2010
    Member:
    #31230
    Messages:
    610
    Gender:
    Male
    First Name:
    Robert
    So Cal
    Vehicle:
    06 Toyota Tacoma Sport 4x4
    Build Thread: http://www.tacomaworld.com/forum/builds/74926-barlowrs-06-taco-expo-build-thread.html OME Lift, FJ SE Wheels, 255/85 KM2, Allpro Plate Bumper, 8K Winch, Synthetic Line, Yaesu FT-8800R, Custom Sliders Sockmonkey bedside decals, BHLM, base model grille, TRD offroad (black) trim
    Broke up with gf, moved out of the house, and decided to take "working remotely" more serious and live in the truck for a few months hunting and fishing everyday. Time to reset myself. Solar keeps my batteries topped and allows me to work during the day, and hunt/fish in the evenings and live indefinitely. Motorcycle allows me to make runs to nearest town if I need to.


  14. Dec 14, 2020 at 7:46 AM
    voilesj11

    voilesj11 Member

    Joined:
    Apr 19, 2020
    Member:
    #325264
    Messages:
    11
    Gender:
    Male
    I got them as a pair, however I got them from Tacomabeast on a Black Friday sale for $350 lol the normal price is too steep for me.

    DG92071 likes this.
  15. Dec 14, 2020 at 7:50 AM
    voilesj11

    voilesj11 Member

    Joined:
    Apr 19, 2020
    Member:
    #325264
    Messages:
    11
    Gender:
    Male
    Another day shot for those of you wondering about them


  16. Dec 14, 2020 at 7:52 AM
    KaroS

    KaroS Well-Known Member

    Joined:
    Jan 12, 2020
    Member:
    #315921
    Messages:
    50
    Gender:
    Male
    First Name:
    Javi
    NE Florida
    Vehicle:
    2006 Tacoma DCSB TRD Offroad
    3" Bilstein 5100, Firestone Airbags & Add a leaf,
    Just gotta learn to use it and i'll be on my way lol

    DG92071 likes this.
  17. Dec 14, 2020 at 7:52 AM
    loyaltothetaco

    loyaltothetaco It's part ATV, part SUV, and certified by the DMV

    Joined:
    Sep 22, 2016
    Member:
    #197953
    Messages:
    1,847
    Gender:
    Male
    First Name:
    Adam
    Bay Area
    Vehicle:
    Radiant Red 2006 DCSB SR5
    2.5" OME lift, 1.25" wheel spacers, 16" trd anthracite wheels wrapped in 265/75/r16 duratracs, tyger tonneau cover, plus a flew other odds and ends. More to come.
    This is possibly the greatest ending to 2020 i can think of, all you need is a dog :101010:

    wi_taco, DG92071, trdtacojef and 8 others like this.
  18. Dec 14, 2020 at 9:00 AM
    banditcamp

    banditcamp Well-Known Member

    Joined:
    May 23, 2018
    Member:
    #254335
    Messages:
    510
    Gender:
    Male
    First Name:
    daniel
    Vehicle:
    2015 Super White DCSB Off Road
    This is the perfect life

    DG92071, GonzoQuick and kidsmoke like this.
  19. Dec 14, 2020 at 9:04 AM
    andrewtheadventurer

    andrewtheadventurer Well-Known Member

    Joined:
    Feb 7, 2017
    Member:
    #209901
    Messages:
    1,877
    First Name:
    Andrew
    Denver
    Vehicle:
    Off-road Tenthouse
    an empty wallet
    What’s up with the AT sticker on a FlipPac?

  20. Dec 14, 2020 at 9:35 AM
    scott_b

    scott_b Well-Known Member

    Joined:
    Oct 31, 2019
    Member:
    #309562
    Messages:
    120
    Gender:
    Male
    The Old North State
    Vehicle:
    '12 TRD Sport AC MT
    Hell. Yes.

    Wish I would have had the balls to do that earlier in life.

    Philrab, DG92071, GonzoQuick and 2 others like this.
