What Have You Done To Your 2nd Gen Tacoma Today?

Discussion in '2nd Gen. Tacomas (2005-2015)' started by kwalton, Feb 2, 2008.

  1. Sep 14, 2018 at 4:59 AM
    TRD4X4Taco

    TRD4X4Taco Well-Known Member

    Joined:
    Sep 23, 2017
    Member:
    #230862
    Messages:
    180
    Gender:
    Male
    First Name:
    Clay
    Dallas, TX
    Vehicle:
    14 TRDS DCSB
    for me its more comfortable sitting like this sitting up right in the seat.

  2. Sep 14, 2018 at 6:59 AM
    JohnnyRed

    JohnnyRed Well-Known Member

    Joined:
    Oct 24, 2016
    Member:
    #200536
    Messages:
    175
    Gender:
    Male
    First Name:
    John
    Northern Kentucky
    Vehicle:
    2008 DCLB TRD Sport
    Made a switched color red/white dome light to go with my switched color map lights.
    20180831_195058.jpg 20180831_195052.jpg

  3. Sep 14, 2018 at 7:44 AM
    308savage

    308savage Well-Known Member

    Joined:
    Mar 6, 2016
    Member:
    #180389
    Messages:
    501
    Gender:
    Male
    First Name:
    Adam
    East Tennessee
    Vehicle:
    2012 Tacoma TRD Sport DCSB
    Leveling kit, Flowmaster exhaust, BFG AT KO2, Warrior Products steps, roll bar
    More pics and info please!

    Voltron4x4 and Kuntrykid like this.
  4. Sep 14, 2018 at 8:34 AM
    JohnnyRed

    JohnnyRed Well-Known Member

    Joined:
    Oct 24, 2016
    Member:
    #200536
    Messages:
    175
    Gender:
    Male
    First Name:
    John
    Northern Kentucky
    Vehicle:
    2008 DCLB TRD Sport
    @308savage

    I bought 4 red and 4 white 12 SMD LED Panel lights on ebay (links at the bottom). I chose the 12 SMD LED because I measured and I don't think the factory housing would hold a larger LED.

    I mounted them in the factory housing and drilled a small hole to run the wires into the back of the housing. I then wired all the grounds together, and connected it to the ground on one of the festoon adapters which the LEDs came with.

    I connected all the red + together, and all the white + together, then ran each of those to a mini SPDT switch (I personally prefer a switched hot instead of a switched ground, but to each their own). So, one pin of the switch receives power from the festoon, then the other 2 pins are connected to the + side of the LEDs.

    I had to dremel out a small channel for the back of the switch to stick through as it's too deep for the factory housing. Then I drilled a hole in the lens to mount the switch to.

    Here you can see the holes I drilled for the wires, and the rectangular cutout I made for the switch to poke through. I don't have a photo of the finished wiring on the switch, but the 3 red wires at the bottom of the photo were connected to the switch:
    20180831_111113.jpg 20180831_111053.jpg


    Red - https://www.ebay.com/itm/2-x-Brilli...terior-Map-Dome-Door-Trunk-Light/130697513592
    White (I'd personally look for a different white, these are much more blue than I'd like. I'd prefer to find something in the 4000k range, these are probably ~6000k) - https://www.ebay.com/itm/4x-White-1...A9S-Dome-Festoon-Adapters-12V-US/171574618646
    Switches - https://www.ebay.com/itm/10PCS-Mini...ition-On-on-Toggle-Switches-M111/401299688736

    Voltron4x4, siundon, BadDNA and 4 others like this.
  5. Sep 14, 2018 at 8:54 AM
    natesmitte500

    natesmitte500 Well-Known Member

    Joined:
    Jun 23, 2017
    Member:
    #222254
    Messages:
    586
    Gender:
    Male
    First Name:
    Nathaniel
    Henry County, GA
    Vehicle:
    Silver 2015 Tacoma
    Dual 185W spot lights, ultra motor sports wheels, 255/75/17 BFG Mud Terrain, patch board (aka roof liner)
    Cool thanks!

  6. Sep 14, 2018 at 9:40 AM
    henrilepuf

    henrilepuf Well-Known Member

    Joined:
    Nov 28, 2012
    Member:
    #92032
    Messages:
    584
    Gender:
    Male
    First Name:
    henri
    Northwestern Paraguay
    Vehicle:
    tacoma 2014 4x4 DCLB
    I've noticed the same at first day.
    Afterwards, all good.
    Good quality stuff

  7. Sep 14, 2018 at 10:02 AM
    308savage

    308savage Well-Known Member

    Joined:
    Mar 6, 2016
    Member:
    #180389
    Messages:
    501
    Gender:
    Male
    First Name:
    Adam
    East Tennessee
    Vehicle:
    2012 Tacoma TRD Sport DCSB
    Leveling kit, Flowmaster exhaust, BFG AT KO2, Warrior Products steps, roll bar
    Thanks!

  8. Sep 14, 2018 at 10:05 AM
    henrilepuf

    henrilepuf Well-Known Member

    Joined:
    Nov 28, 2012
    Member:
    #92032
    Messages:
    584
    Gender:
    Male
    First Name:
    henri
    Northwestern Paraguay
    Vehicle:
    tacoma 2014 4x4 DCLB
    What's the exact english name for this rubber piece ??
    I need to order a new one.
    Thanks

  9. Sep 14, 2018 at 10:11 AM
    oni06

    oni06 Well-Known Member

    Joined:
    Jul 1, 2016
    Member:
    #191029
    Messages:
    2,513
    Gender:
    Male
    First Name:
    Keith
    Harbor City, CA
    CV Boot

    Stryker420 and henrilepuf like this.
  10. Sep 14, 2018 at 10:19 AM
    henrilepuf

    henrilepuf Well-Known Member

    Joined:
    Nov 28, 2012
    Member:
    #92032
    Messages:
    584
    Gender:
    Male
    First Name:
    henri
    Northwestern Paraguay
    Vehicle:
    tacoma 2014 4x4 DCLB
    I guess I can run the truck with this damaged boot till I get the new one.

    Stryker420 likes this.
  11. Sep 14, 2018 at 10:20 AM
    oni06

    oni06 Well-Known Member

    Joined:
    Jul 1, 2016
    Member:
    #191029
    Messages:
    2,513
    Gender:
    Male
    First Name:
    Keith
    Harbor City, CA
    Your just gonna fling the grease all over the place doing that.

  12. Sep 14, 2018 at 10:24 AM
    AugustaTaco

    AugustaTaco Well-Known Member

    Joined:
    May 22, 2015
    Member:
    #155836
    Messages:
    1,289
    Gender:
    Male
    First Name:
    Josh
    Augusta, GA
    Vehicle:
    2015 XSP-X 4wd
    "Getting out of hand" - Wife
    In the conditions you run your truck, dirt is going to get into the boot and probably start messing up the constant velocity (CV) joint that the boot is trying to protect

    It's a lot more expensive if you have to replace the whole cv axle

  13. Sep 14, 2018 at 10:25 AM
    tbr3345

    tbr3345 Well-Known Member

    Joined:
    Jan 20, 2016
    Member:
    #175522
    Messages:
    166
    Gender:
    Male
    First Name:
    Tom
    Sacramento, CA
    Vehicle:
    2010 TRD Sport DBL Cab Silver Streak Mica
    Did something positive to day. Installed my MESO Ultimate Map Lights. Love the way they look much better than Toyota's, Have both the Dome and Maps no, I can see in the dark.

  14. Sep 14, 2018 at 10:28 AM
    henrilepuf

    henrilepuf Well-Known Member

    Joined:
    Nov 28, 2012
    Member:
    #92032
    Messages:
    584
    Gender:
    Male
    First Name:
    henri
    Northwestern Paraguay
    Vehicle:
    tacoma 2014 4x4 DCLB
    Thanks a lot

    gabbo2112, Rick_Taco and AugustaTaco like this.
  15. Sep 14, 2018 at 10:31 AM
    Oz Loya

    Oz Loya Member

    Joined:
    Apr 21, 2018
    Member:
    #251263
    Messages:
    17
    Gender:
    Male
    First Name:
    Oz
    Chihuahua, MX
    Vehicle:
    2007 Jet Black Tacoma TRD Sport
  16. Sep 14, 2018 at 11:34 AM
    Beer-toe

    Beer-toe Well-Known Member

    Joined:
    Apr 3, 2018
    Member:
    #249325
    Messages:
    119
    First Name:
    Robert
    more pics of your rack jack and how you mounted please. and how well does it hold? looking to do the same thing for my jack

  17. Sep 14, 2018 at 12:00 PM
    azhiaziam

    azhiaziam Well-Known Member

    Joined:
    Feb 8, 2014
    Member:
    #122554
    Messages:
    1,912
    Gender:
    Male
    Clovis
    So need to do this

  18. Sep 14, 2018 at 12:20 PM
    Alexely999

    Alexely999 Well-Known Member

    Joined:
    Jan 17, 2016
    Member:
    #175203
    Messages:
    982
    Gender:
    Male
    First Name:
    Alex
    Bay Area, CA
    Vehicle:
    2015 DCSB 4X4
    Purrfect

  19. Sep 14, 2018 at 12:21 PM
    Musubi3

    Musubi3 Well-Known Member

    Joined:
    May 16, 2016
    Member:
    #187108
    Messages:
    296
    Gender:
    Male
    Hawaii
    Vehicle:
    2014 Tacoma DC 4x4 TRD Off Road
    I installed MESO's dome and map lights. I still have a tan from lights' intensity.

  20. Sep 14, 2018 at 1:20 PM
    Boylemaker88

    Boylemaker88 Member

    Joined:
    Jan 16, 2016
    Member:
    #175162
    Messages:
    18
    Gender:
    Male
    First Name:
    Thomas
    Rockledge FL
    Vehicle:
    2013 Tacoma
