Anytime Foglight mod explained electrical (diagrams)

Discussion in 'Lighting' started by Crom, Dec 6, 2009.

  1. Feb 23, 2010 at 10:37 AM
    #41
    ShadowFalken

    ShadowFalken Well-Known Member

    Joined:
    Dec 30, 2009
    Member:
    #28480
    Messages:
    302
    Gender:
    Male
    First Name:
    Jim
    Maryland
    Vehicle:
    10 Off Road
    Raptor stainless bars, Wet Okole covers, RollBak bed cover, PopNLock, Redline hood struts, XM radio factory kit
    I hope as many people use these as possible. They have made me lots of money over the years due to damaged and corroded wiring. More of an issue outside the vehicle than inside the vehicle but they are still bad news. They cut through the insulation AND the wire in many cases, causing a weak spot and an easy place for a failure.

    I recently purchased a new trailer and almost declined the purchase when I found these items in the harness. Pure speed without durability taken into account. Soooooo many speaker issues, inop lights, no starts, security codes and the list goes on have been traced to these little gems. Go the extra mile, it is rarely crowded out there and your work will last.

    Not trying to be mean, just sayin.



  2. Feb 23, 2010 at 11:39 AM
    #42
    ROCKSLINGER

    ROCKSLINGER Zombie Response Team

    Joined:
    Apr 1, 2009
    Member:
    #15439
    Messages:
    579
    Gender:
    Male
    First Name:
    Robert
    Reno Nv
    Vehicle:
    14 MGM DBL CAB 6 SPEED
    Fox Coilover with reservoir, Fox Remote Rear reservoir, Wheeler's 3 pack AAL, Grillcraft Grille color matched, Rampage 50" LED Light Bar, Relentless 1/4" IFS-Mid and Transfer case Skids, Relentless High Clearance Rear Bumper, Kenwood 1800 watt Amp, 12" Rockford Fosgate P3 Shallow Sub, 1 Farad Capacitor, Redline Hood Struts, Weathertech Floor Mats, Doug Thorley Long Tube Headers, Flowmaster Delta 40, URD MAF Calibrator, URD Short Shifter, CST Black Leather W/Red Stich, On Board Air, Train Horns,
    Has anyone done this and ran it to the tails or running light instead of them being tied in to the ignition? Just wondering which wire it might be so all I have to do is turn my switch one time to the running lights?

  3. Feb 23, 2010 at 3:01 PM
    #43
    Crom

    Crom [OP] Time is precious; use it wisely

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    4,199
    Gender:
    Male
    First Name:
    Mr. Sir
    San Diego, CA
    Vehicle:
    2009 Double Cab 4x4 Off Road
    A.R.E. MX Shell & Yakima Rack, Stubbs HD-SKO Rock Sliders, JBA UCA's & OME 885 Coils and nitrochargers, Dakar leaf packs, u-bolt flip, Flat BajaRack, Kenwood VHF/UHF Radio, Aux Battery, Solar Panels, L-Track everywhere, Goodyear Duratracs, Secured tailgate, 7-pin relocation, Inverter 400W all time, In-cab 110v outlets, Rear-seat 12v outlets., Steering shaft TSB, anytime fogs, DTRL toggle switch, aux turn signals, Diff Breather, ImMrYo mirror bracket, ABS Kill switch, (2) Kid Car Seats, and a Glock 23 with night sights.
    ShadowFalken is correct. Quicksplices are not ideal and can introduce electrical problems down the road.

    Please see Please see jivewalker's method which does not require a splice!


    Robert you can examine technical documentation and use another source for the relay. The ignition wire has worked well since at least 2007. Before that people were tapping into the emission circuit but people had issues with that.

    It's kind of funny. People who used the emissions circuit had their fogs come for a minute or two about 5 hours after their trucks were off. Apparently their is logic which activates when the truck is off which attempts to detect fuel leaks or something similar. It's in your owners manual and you can read about it there.

    If your so inclined try using some documentation to find an alternate circuit if you wish.

    http://www.ncttora.com/fsm/05+/local...es/repair.html

  4. Feb 23, 2010 at 4:51 PM
    #44
    ROCKSLINGER

    ROCKSLINGER Zombie Response Team

    Joined:
    Apr 1, 2009
    Member:
    #15439
    Messages:
    579
    Gender:
    Male
    First Name:
    Robert
    Reno Nv
    Vehicle:
    14 MGM DBL CAB 6 SPEED
    Fox Coilover with reservoir, Fox Remote Rear reservoir, Wheeler's 3 pack AAL, Grillcraft Grille color matched, Rampage 50" LED Light Bar, Relentless 1/4" IFS-Mid and Transfer case Skids, Relentless High Clearance Rear Bumper, Kenwood 1800 watt Amp, 12" Rockford Fosgate P3 Shallow Sub, 1 Farad Capacitor, Redline Hood Struts, Weathertech Floor Mats, Doug Thorley Long Tube Headers, Flowmaster Delta 40, URD MAF Calibrator, URD Short Shifter, CST Black Leather W/Red Stich, On Board Air, Train Horns,
    ^^--- OK Thanks I wasnt sure if anyone had done it so I didnt have to start testing wires. Ill search other post as well.

  5. Feb 23, 2010 at 9:44 PM
    #45
    ROCKSLINGER

    ROCKSLINGER Zombie Response Team

    Joined:
    Apr 1, 2009
    Member:
    #15439
    Messages:
    579
    Gender:
    Male
    First Name:
    Robert
    Reno Nv
    Vehicle:
    14 MGM DBL CAB 6 SPEED
    Fox Coilover with reservoir, Fox Remote Rear reservoir, Wheeler's 3 pack AAL, Grillcraft Grille color matched, Rampage 50" LED Light Bar, Relentless 1/4" IFS-Mid and Transfer case Skids, Relentless High Clearance Rear Bumper, Kenwood 1800 watt Amp, 12" Rockford Fosgate P3 Shallow Sub, 1 Farad Capacitor, Redline Hood Struts, Weathertech Floor Mats, Doug Thorley Long Tube Headers, Flowmaster Delta 40, URD MAF Calibrator, URD Short Shifter, CST Black Leather W/Red Stich, On Board Air, Train Horns,
    Ok so I figured it out! Here is what I did!
    [​IMG]
    I did a quick solder job instead of using connectors!
    Now I can turn my headlight switch to the running lights/tails and my fog lights will turn on. They still work with the factory switch as well so if I dont want them on they can turn off! Everything seems to be working well.
    NO SPLICING INTO THE IGNITION WIRE!:D

  6. Feb 23, 2010 at 10:08 PM
    #46
    ShadowFalken

    ShadowFalken Well-Known Member

    Joined:
    Dec 30, 2009
    Member:
    #28480
    Messages:
    302
    Gender:
    Male
    First Name:
    Jim
    Maryland
    Vehicle:
    10 Off Road
    Raptor stainless bars, Wet Okole covers, RollBak bed cover, PopNLock, Redline hood struts, XM radio factory kit
    So you tapped into the trailer light relay. I assume you have the towing package, right?

    Do you see the female spade just to the right of your upper solder tab? It is an empty relay socket that is not used. It should be wired into switched power. You can check it with a test light. You could then put a male spade on your wire and plug it in there.

    What you did works and avoids cutting into a wire. I like how you routed it cleanly in the box. You can also use these........


    http://order.waytekwire.com/productdetail2/M37/46045/ATO%20FUSE%20CIRCUIT%20TAP/

    You never know what else you may want to add one day. :)

  7. Feb 23, 2010 at 10:19 PM
    #47
    Crom

    Crom [OP] Time is precious; use it wisely

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    4,199
    Gender:
    Male
    First Name:
    Mr. Sir
    San Diego, CA
    Vehicle:
    2009 Double Cab 4x4 Off Road
    A.R.E. MX Shell & Yakima Rack, Stubbs HD-SKO Rock Sliders, JBA UCA's & OME 885 Coils and nitrochargers, Dakar leaf packs, u-bolt flip, Flat BajaRack, Kenwood VHF/UHF Radio, Aux Battery, Solar Panels, L-Track everywhere, Goodyear Duratracs, Secured tailgate, 7-pin relocation, Inverter 400W all time, In-cab 110v outlets, Rear-seat 12v outlets., Steering shaft TSB, anytime fogs, DTRL toggle switch, aux turn signals, Diff Breather, ImMrYo mirror bracket, ABS Kill switch, (2) Kid Car Seats, and a Glock 23 with night sights.
    Kudos to you my friend! :thumbsup:

    You took pin 1 of the Fog relay and connected it to pin #3 of the Towing Tail Relay.

    While your fogs will work anytime now... I don't think your tow lights will work if you connected your 7-pin connector to a trailer in that configuration.

    You are proving a really good point though. All we're really trying to do is provide 12v to pin #1 of the fog relay.


    ShadowFalken, Very interesting observation. If I have some time I'll try with a test light and see. I looked at a diagram where that female spade connector is and it looks like it may be hot all the way back to the fuseblock engine #2 wire for 1GR-FE engine. Take a look at this diagram if your interested.

    I'm glad we're having this discussion because we'll come up with a better method. I never really liked tapping the ignition circuit, it always kind of bothered me--the risk does not equal the reward.

  8. Feb 23, 2010 at 11:34 PM
    #48
    ShadowFalken

    ShadowFalken Well-Known Member

    Joined:
    Dec 30, 2009
    Member:
    #28480
    Messages:
    302
    Gender:
    Male
    First Name:
    Jim
    Maryland
    Vehicle:
    10 Off Road
    Raptor stainless bars, Wet Okole covers, RollBak bed cover, PopNLock, Redline hood struts, XM radio factory kit
    I have not checked mine Crom, but I will when I get back to the shop.

    I did not have this MOD on my list because of how the Maryland inspection regs are written. If Fogs can come on with anything but low beams I am almost positive it is supposed to fail inspection and could get you an "equipment ticket" you have to take to an inspector. Dangit.

    You may be right, it might be hot at all times. Worth a look though.

  9. Feb 23, 2010 at 11:39 PM
    #49
    PRBulldog36

    PRBulldog36 Well-Known Member

    Joined:
    Feb 10, 2010
    Member:
    #31134
    Messages:
    450
    Gender:
    Male
    First Name:
    Juan
    San Antonio, Texas
    Vehicle:
    2006 PreRunner SR5 TRD Off Road
    Bilsteins 5100's X4 front set at 2.5 and rear AAL,BFG Rugged Trail T/A P265/65R/17, Warrior 375 17X8 Wheels with Gorilla locks,Black Billet Grille top and bottom and replaced Toyo emblem with Dallas Cowboys Star by MetalMiller, Vent Shade window louvers and hood bug shield, Fog light anytime mod,Dome light Mod,Blue interior LED's, Six inch Black Chrome billet antenna,Firestik CB Antenna, Cobra 75 CB, 12Vt/DC outlet back of Center Console, CB external speaker, Sirius Satellite Radio, Westin tube step up bars (Chrome), Tinted windows (legal), Eyebrow on windshield (Limo),Leather arm rest mod,HID H4's(fog), HID plug and play 8000, Tailgate theft prevention mod and Tailgate Pop-n-Lock, Trailer hitch brake light,Garmin GPS Dashboard Mount, Baja Lights on the rear bed rail, In Bed Mt Bike carrier, Tail gate extender, N-Fab light bar with Four Hella 500's, Fold down antenna,WeatherTech digital floor mats, mount,Kenwood head unit, Polk Audio 6X9,Two 12 ' Subs MTX, Kenwood Excellon 5 1/4, Ke
    I just did the anytime fog mod this weekend. It's easier than it looks. Time to change the bulbs now !

  10. Feb 24, 2010 at 12:28 AM
    #50
    ROCKSLINGER

    ROCKSLINGER Zombie Response Team

    Joined:
    Apr 1, 2009
    Member:
    #15439
    Messages:
    579
    Gender:
    Male
    First Name:
    Robert
    Reno Nv
    Vehicle:
    14 MGM DBL CAB 6 SPEED
    Fox Coilover with reservoir, Fox Remote Rear reservoir, Wheeler's 3 pack AAL, Grillcraft Grille color matched, Rampage 50" LED Light Bar, Relentless 1/4" IFS-Mid and Transfer case Skids, Relentless High Clearance Rear Bumper, Kenwood 1800 watt Amp, 12" Rockford Fosgate P3 Shallow Sub, 1 Farad Capacitor, Redline Hood Struts, Weathertech Floor Mats, Doug Thorley Long Tube Headers, Flowmaster Delta 40, URD MAF Calibrator, URD Short Shifter, CST Black Leather W/Red Stich, On Board Air, Train Horns,
    Yeah damn knew there was something! Well I also know it works by puting the wire in with the relay without bending it and leaving it out. So I can do that. Im going to try and find the actual wire for the running lights that goes into the box and tap into that.

  11. Feb 24, 2010 at 8:35 AM
    #51
    Crom

    Crom [OP] Time is precious; use it wisely

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    4,199
    Gender:
    Male
    First Name:
    Mr. Sir
    San Diego, CA
    Vehicle:
    2009 Double Cab 4x4 Off Road
    A.R.E. MX Shell & Yakima Rack, Stubbs HD-SKO Rock Sliders, JBA UCA's & OME 885 Coils and nitrochargers, Dakar leaf packs, u-bolt flip, Flat BajaRack, Kenwood VHF/UHF Radio, Aux Battery, Solar Panels, L-Track everywhere, Goodyear Duratracs, Secured tailgate, 7-pin relocation, Inverter 400W all time, In-cab 110v outlets, Rear-seat 12v outlets., Steering shaft TSB, anytime fogs, DTRL toggle switch, aux turn signals, Diff Breather, ImMrYo mirror bracket, ABS Kill switch, (2) Kid Car Seats, and a Glock 23 with night sights.
    Okay, This post brings everything full circle for me. There is a good reason the ignition wire was used as a +12v source for this mod. Any other +12v source in the fuse box is ALWAYS HOT.

    I believe if one of us tried to use any other +12v source in the fuse box, he/she would be able to run the fogs without the ignition on. This is fine--however most people will not want that because of the risk of accidentally forgetting to turn them off and draining the battery.

    That was the whole reason someone came up with the idea of using the ignition wire. It's only hot when the keys are in the ignition and its in the "ON" position.

    Here is an illustrated picture from a test I did this morning.

    [​IMG]

  12. Mar 7, 2010 at 3:18 PM
    #52
    BigA

    BigA Hey you'll watch this!!!

    Joined:
    Apr 4, 2008
    Member:
    #5732
    Messages:
    130
    Gender:
    Male
    First Name:
    A
    Yadkinville,NC
    Vehicle:
    07 sr5 tacomo trd debadged
    12v outlet power always on, fog light on anytime, Window tint, Extra D-Rings in bed, cheap anti theft tailgate mod, hidden garage door opener,LEDS in the map lights and the floor boards and in the main light,DTRL mod w/ factory relay and harness
    Didnt like the idea of bending the prong on my relay made up some wires pigtails what have you and oput male and female ends on them worked pretty good and tucked right under the fuse box cover!!


  13. Mar 7, 2010 at 3:22 PM
    #53
    trdracing38

    trdracing38 Member

    Joined:
    Mar 26, 2009
    Member:
    #15171
    Messages:
    11
    Gender:
    Male
    Anaheim
    Vehicle:
    08 Prerunner
    TRD CAI & TRD Cat-Back Exhaust...also equipped with interior LEDs under dash and front seats and the handy Escort Passport 9500ix
    Well thats definitely a good idea but more messy and more work.....

  14. Mar 7, 2010 at 3:29 PM
    #54
    BigA

    BigA Hey you'll watch this!!!

    Joined:
    Apr 4, 2008
    Member:
    #5732
    Messages:
    130
    Gender:
    Male
    First Name:
    A
    Yadkinville,NC
    Vehicle:
    07 sr5 tacomo trd debadged
    12v outlet power always on, fog light on anytime, Window tint, Extra D-Rings in bed, cheap anti theft tailgate mod, hidden garage door opener,LEDS in the map lights and the floor boards and in the main light,DTRL mod w/ factory relay and harness
    yeah but its coverd up by the fuse box lid and alot easier to reverse if i ever trade it in ha i mean when my great grandson trades my truck in!!

  15. Mar 7, 2010 at 7:52 PM
    #55
    Crom

    Crom [OP] Time is precious; use it wisely

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    4,199
    Gender:
    Male
    First Name:
    Mr. Sir
    San Diego, CA
    Vehicle:
    2009 Double Cab 4x4 Off Road
    A.R.E. MX Shell & Yakima Rack, Stubbs HD-SKO Rock Sliders, JBA UCA's & OME 885 Coils and nitrochargers, Dakar leaf packs, u-bolt flip, Flat BajaRack, Kenwood VHF/UHF Radio, Aux Battery, Solar Panels, L-Track everywhere, Goodyear Duratracs, Secured tailgate, 7-pin relocation, Inverter 400W all time, In-cab 110v outlets, Rear-seat 12v outlets., Steering shaft TSB, anytime fogs, DTRL toggle switch, aux turn signals, Diff Breather, ImMrYo mirror bracket, ABS Kill switch, (2) Kid Car Seats, and a Glock 23 with night sights.
    Very creative BigA. It got the job done. :thumbsup:

  16. Mar 8, 2010 at 2:44 AM
    #56
    BigA

    BigA Hey you'll watch this!!!

    Joined:
    Apr 4, 2008
    Member:
    #5732
    Messages:
    130
    Gender:
    Male
    First Name:
    A
    Yadkinville,NC
    Vehicle:
    07 sr5 tacomo trd debadged
    12v outlet power always on, fog light on anytime, Window tint, Extra D-Rings in bed, cheap anti theft tailgate mod, hidden garage door opener,LEDS in the map lights and the floor boards and in the main light,DTRL mod w/ factory relay and harness
    Thanks Crom :taco: <----- didnt know we had so many things we could put in our post

  17. Mar 28, 2010 at 4:49 PM
    #57
    eskamo23

    eskamo23 Well-Known Member

    Joined:
    Oct 17, 2009
    Member:
    #24463
    Messages:
    382
    Gender:
    Male
    Pasadena, CA
    Vehicle:
    trd sport
    TRD cai with (AFE dry flow filter), de-flapped, tint, weathertech floor liners,coverking neoprene seat covers, rear TSB, Billy 5100's set at 1.75'', Pro Comp 7005's 17x8 BS4.5, any time fogs, tailgate theft mod, led lights in the int., slim cubby HID headlights and fogs, TRD skid plate, bed mat
    well just did this mod. and it was quick and pretty simple. it didnt work at first but then i realized i didnt crimp down the spilce tap connector enuff. thanks for the help and pics in the write up!!!!!! +1

  18. May 2, 2010 at 3:06 PM
    #58
    schus21

    schus21 Well-Known Member

    Joined:
    Apr 7, 2010
    Member:
    #34821
    Messages:
    45
    Gender:
    Male
    Georgia
    Vehicle:
    2010 Tacoma TRD Sport DC
    Just finished up this mod. The pics were a great help and everything works perfectly. Thank you!

  19. May 2, 2010 at 5:41 PM
    #59
    Crom

    Crom [OP] Time is precious; use it wisely

    Joined:
    Jun 22, 2009
    Member:
    #18782
    Messages:
    4,199
    Gender:
    Male
    First Name:
    Mr. Sir
    San Diego, CA
    Vehicle:
    2009 Double Cab 4x4 Off Road
    A.R.E. MX Shell & Yakima Rack, Stubbs HD-SKO Rock Sliders, JBA UCA's & OME 885 Coils and nitrochargers, Dakar leaf packs, u-bolt flip, Flat BajaRack, Kenwood VHF/UHF Radio, Aux Battery, Solar Panels, L-Track everywhere, Goodyear Duratracs, Secured tailgate, 7-pin relocation, Inverter 400W all time, In-cab 110v outlets, Rear-seat 12v outlets., Steering shaft TSB, anytime fogs, DTRL toggle switch, aux turn signals, Diff Breather, ImMrYo mirror bracket, ABS Kill switch, (2) Kid Car Seats, and a Glock 23 with night sights.
    You're welcome! ;)

    Welcome to the forums! Glad you found everything so helpful. :)

  20. May 3, 2010 at 3:44 PM
    #60
    Isthatahemi

    Isthatahemi Well-Known Member

    Joined:
    Apr 29, 2009
    Member:
    #16582
    Messages:
    1,160
    Gender:
    Male
    Vehicle:
    TRD OFF ROAD
    BFG AT's, Weathertechs, Hoppy's brake controller.
