Rear Diff Lock

Discussion in '2nd Gen. Tacomas (2005-2015)' started by yoda606, Aug 15, 2011.

  1. Aug 15, 2011 at 7:13 PM
    #1
    yoda606

    yoda606 [OP] New Member

    Joined:
    Aug 15, 2011
    Member:
    #61771
    Messages:
    2
    Gender:
    Male
    Vehicle:
    2005 Tacoma 4.0L 4x4 6spd
    I have a 2005 Tacoma 4.0L 6spd with the TRD Off Road package and I would like to be able to lock up the rear end in 4H and 2H instead of 4L. Ive heard of mods for the older Tacomas but havent found anything for the newers ones. If it is possible to lock it up out of 4L would it not damage the rear end?

  2. Aug 15, 2011 at 7:14 PM
    #2
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,996
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
  3. Aug 15, 2011 at 7:54 PM
    #3
    yoda606

    yoda606 [OP] New Member

    Joined:
    Aug 15, 2011
    Member:
    #61771
    Messages:
    2
    Gender:
    Male
    Vehicle:
    2005 Tacoma 4.0L 4x4 6spd
    I saw the mod but it seemed kind of complicated and I didnt really like how much cutting you have to do to the wires or the fact you could engage it at any speed. Is the any other ways to go about doing it?

  4. Aug 16, 2011 at 8:44 AM
    #4
    David K

    David K Well-Known Member

    Joined:
    Jun 27, 2009
    Member:
    #18969
    Messages:
    9,996
    Gender:
    Male
    San Marcos, Alta California
    Vehicle:
    2010 4WD Off Road DC
    Differential Breather Mod Light Bar: 2 Hella 4000 HID, 1 Cibie Halogen. Bilstein 5100s Ride Rite Air Bags
    You can do a lot of things with your Tacoma, but that doesn't mean you should... Here is the sticker that is on the driver's door that says what the rear locker should be used for and the max. speed when using it:

    [​IMG]

  5. Aug 16, 2011 at 9:19 AM
    #5
    BlueT

    BlueT Well-Known Member

    Joined:
    Mar 30, 2009
    Member:
    #15341
    Messages:
    5,645
    Gender:
    Male
    NorthEast
    Vehicle:
    07 Dbl Cab LB with LSD
    I moded 1999 Taco so much it had turned to Land Cruiser
    5 mph is a limit when to operate (as in engage or disengage) locker) Reason for that is when locker tries to engage a sleve with splines needs to slide over the collar, also with splines. Too much speed and those splines can be bend if they are not fully seated. So hence the limit. Once splines are fully locked in place you can go as fast as you want. it makes no difference to locker anymore.
    Hence why some people bend those splines because they are engaging locker while spinning tires madly. :D

  6. Aug 16, 2011 at 10:34 AM
    #6
    Black3144

    Black3144 Well-Known Member

    Joined:
    Jul 6, 2011
    Member:
    #59438
    Messages:
    61
    Gender:
    Male
    Bellevue, NE
    Vehicle:
    '07 TRD Off Road
    Just do the relay mod and get the DC relay and not the AC one, took me about 2 hours. If you do the switch I believe it won't turn off your ABS which you want to do.
