Tacoma Spring refurbishing

Discussion in 'Suspension' started by 4WD, Dec 22, 2011.

Thread Status:
Not open for further replies.
  1. Jan 16, 2013 at 7:32 PM
    #1201
    Sandman614

    Sandman614 Ex-Snarky TWSS elf, Travis #hotsavannahdotcom

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    36,024
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    Lengths will be different being different gens, your leaf center puns are not centered if I recall. The ride is what I wanted, I have yet to put a load in it to see how they stand up there, I don't bottom out with 4 passengers going over a speed bump now. :thumbsup:Doug and this mod are awesome!

  2. Jan 16, 2013 at 10:02 PM
    #1202
    4WD

    4WD [OP] cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,530
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    Haha, thanks Rick I've got a design just need to bring it to life...:)


    Just PM'd back...;)


    Thanks brother, much appreciated . I always get all warm & fuzzy when the results someone else gets meets or exceeds expectations...:D

  3. Jan 17, 2013 at 9:22 AM
    #1203
    SoCaltaco65

    SoCaltaco65 Well-Known Member

    Joined:
    May 10, 2011
    Member:
    #56389
    Messages:
    7,653
    Gender:
    Male
    Vehicle:
    2011 DCSB 4x4 Offroad TRD
    Hmmm, not a bad idea, at the very least a logo Doug, have to chat with the wife about coming up with a logo for you, with your input of course.

  4. Jan 17, 2013 at 9:23 AM
    #1204
    Sandman614

    Sandman614 Ex-Snarky TWSS elf, Travis #hotsavannahdotcom

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    36,024
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    I'd put one on the truck!

  5. Jan 17, 2013 at 9:41 AM
    #1205
    wareagle1

    wareagle1 Well-Known Member

    Joined:
    May 2, 2012
    Member:
    #78068
    Messages:
    458
    Gender:
    Male
    First Name:
    Brad
    Fayetteville, TN
    Vehicle:
    07 Tundra DC 5.7
    notta
    x2

  6. Jan 17, 2013 at 10:05 AM
    #1206
    Gear Head

    Gear Head Well-Known Member

    Joined:
    Oct 27, 2012
    Member:
    #89921
    Messages:
    4,630
    Gender:
    Male
    First Name:
    Jacob
    Winston Salem, NC
    Vehicle:
    96 Tacoma
    fj60 front, fj80 rear, full hydro, 5.29's, welded, twin sticked 2.28/4.70 duals, 39.5's, inboarded 63's
    Haha nice! Well hopefully someone can chime in with the length that I should use for what I'm trying to accomplish. I may just cut it to match the toyo 2nd. But for now I'll see where searching can get me.

  7. Jan 17, 2013 at 4:04 PM
    #1207
    4WD

    4WD [OP] cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,530
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now

    Hi Jacob I heard your cry for help brother !! j/k:D

    If you want to firm things up without lift, see if you can find a Dodge dakota in the local wrecking yard, they're known for sitting fairly low , yet have a 3/4 ton rating (that means less ARC, slightly thicker leafs )

  8. Jan 17, 2013 at 4:07 PM
    #1208
    4WD

    4WD [OP] cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,530
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    You guys are gonna make me do it huh ???...:eek::eek:

  9. Jan 17, 2013 at 4:15 PM
    #1209
    uscg2008

    uscg2008 Well-Known Member

    Joined:
    Nov 6, 2009
    Member:
    #25537
    Messages:
    2,879
    Gender:
    Male
    First Name:
    coby
    San Diego, CA originally from Huntington Beach, CA
    Vehicle:
    06 trd sr5 four door 4x4
    CLICK ON SIGNATURE>>>>
    Got to add my name to this list now.


    Current OMD spring users.....

    So far there are these members running my springs:

    1 myself 1st gen

    2 Recklesstaco (matt)- 2nd gen

    3 taco_me_elmo (micah) 1st gen

    4 00taco00 (Reagan) 1st gen

    5 CSJUMPER2003 (chris) 2nd gen 4x

    6 Gregero (Greg) -2nd gen.

    7 Donnod - 2nd gen (out of Las Vegas)

    8 S.B. (Sean)-2nd gen. is getting ready to do this MOD also

    9 Tmectaco79 (Adam) -2nd gen is pending

    10 Fiddynut- 1st gen. he just did this

    11 Enduromatic (matt) 1st gen (Oregon)

    12 goufcustom (michael) 2nd gen

    13 Res4cue (John) 2nd gen

    14 Yotakid62 (Forrest) 1st gen (North Dakota)

    15 PT_LAW (Steve) 1st gen. (Mass.)

    16 01Tac0ma (Chad) 1st gen (SC)

    17 TRd7 1st gen (SC)

    18. Jdaniel1274 (1st gen.) (L.A.)

    19. dad32509 2nd gen. (Dave)

    20. Strohski (Chris) 2nd. gen. (Norcal) building his this week

    21. Sportsterchop200 1st gen. (central Florida)

    22. DWRECK (Derek) 2nd gen. Las Vegas

    23. Leoffensive (Leo) 2nd gen.

    24. LazyMF (Canada)

    25. cayucostacoma 2nd gen. Chris

    26. gdry06 (gary) 2nd. gen

    27. Wareagle1 (Brad) 2nd gen

    28. socaltaco65 (Erik) 2nd gen

    29. White Toy Taco (Gian) 1st gen. Albuquerque, New Mexico

    30. Tmectaco79 (Adam) 2nd gen.

    31. Wolftree (Rick) 2nd gen single cab 4x Ohio

    32.Sandman614 2nd gen. Boone,NC

    33. Uscg2008(coby) 2nd gen dblc 4x Kodiak, ak

    I'm still missing some...

  10. Jan 17, 2013 at 4:17 PM
    #1210
    4WD

    4WD [OP] cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,530
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    This is one of Matt's doodles (RecklessTaco, damn i miss that guy..:()

    I like it , except I'd do away with the Junkyard thing (or maybe not):confused:


    But I def. like what he's done here...


    [​IMG]

  11. Jan 17, 2013 at 5:45 PM
    #1211
    wolftree

    wolftree Well-Known Member

    Joined:
    Oct 9, 2011
    Member:
    #64877
    Messages:
    683
    Gender:
    Male
    First Name:
    Rick
    Ohio
    Vehicle:
    2011 Tacoma 4x4 Regular cab automatic trans,
    Rear Leaf TSB, Bilstein 5100s, extra leaf added
    Remove "junkyard" replace with "Road Tested"

  12. Jan 17, 2013 at 7:31 PM
    #1212
    Sandman614

    Sandman614 Ex-Snarky TWSS elf, Travis #hotsavannahdotcom

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    36,024
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    Just leave it at OMD with the springs. Could think about giving the final design to "local" vinyl printers to spread out the work. RuggedT had posted a vinyl printing thread with the Virginia guys.

    Also, what's OMD:notsure:

  13. Jan 17, 2013 at 8:20 PM
    #1213
    nfs257

    nfs257 Well-Known Member

    Joined:
    Jun 22, 2011
    Member:
    #58691
    Messages:
    7,530
    Gender:
    Male
    First Name:
    Chris
    DFW
    Vehicle:
    She gone
    Old Man Doug

  14. Jan 17, 2013 at 8:22 PM
    #1214
    Sandman614

    Sandman614 Ex-Snarky TWSS elf, Travis #hotsavannahdotcom

    Joined:
    Oct 26, 2010
    Member:
    #45273
    Messages:
    36,024
    Gender:
    Male
    First Name:
    Tim
    Garner, NC/Boone, NC
    Vehicle:
    '06 SR5 Off Road
    ARB Front Bumper, Projector Headlights w/Slimcubby 4300K HID's, Oznium LED's, LED taillights, DIY Washable Cabin Moose Filter, Sockmonkey SR5 Off Road, Aux Audio plug, OME 886x, OME Nitrochargers, Wheelers 3 Leaf Progressive AAL, ImMrYo Rear-View Mirror Lift Bracket, Dodge D-Rings
    :thumbsup:

  15. Jan 17, 2013 at 9:36 PM
    #1215
    4WD

    4WD [OP] cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,530
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    OLd Moldy & Dank...



    ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^

    chris knows haha... I think it started one day when I was doing some springs for Matty (RecklessTaco), we were looking at them & he said they look like OME's & I said " Bullshit, these are OMD's " Matt says "OMD?" & I muttered "Old Man Dougs" We were about half fucked up, laughed for about half an hour & the name just kinda stuck,, besides I'm older than Emu anyway...:eek::p:)


    & yeah I'll have it cleaned up & lookin' right before it goes into print...

  16. Jan 18, 2013 at 5:42 AM
    #1216
    Blutus

    Blutus Active Member

    Joined:
    Nov 5, 2012
    Member:
    #90555
    Messages:
    38
    Gender:
    Female
    Whoa, you mean there's a NEW Mexico??
    Vehicle:
    1998 Tacoma SR5 V6 4wd
    I was thinking the same thing. Nice design! :)

  17. Jan 20, 2013 at 3:09 PM
    #1217
    93civEJ1

    93civEJ1 Well-Known Member

    Joined:
    Aug 8, 2008
    Member:
    #8411
    Messages:
    584
    Gender:
    Male
    Vehicle:
    09 DC TRD OR
    Procomp 6" Stage 1, Bilstein 5100's in front, flowmaster 40 series
    Is there a combo we can use with say a TSB pack to replace a Pro Comp AAL and block....to get 6" that is currently on a truck rear...just want no block.

  18. Jan 20, 2013 at 4:27 PM
    #1218
    UrPebkac

    UrPebkac Well-Known Member

    Joined:
    Jan 20, 2013
    Member:
    #95649
    Messages:
    820
    Gender:
    Male
    First Name:
    David
    RI
    Vehicle:
    2016 GMC SIERRA
    Hello All,
    This is my first post so forgive any errors. I purchased my truck used with 59K mile in Sept. I have been following this thread since Thanksgiving when I drove my atv 2100 miles for hunting season in my bed. Leading me here for obvious reasons.

    I am a "do it myself" type person and this thread was just what I was looking for.

    Here is what I have gathered so far reading through for my 2 gen.


    Take notes:
    Throw a tape measure across your springs, they should be around 2.5" wide.
    Record your width.
    Make sure the donor leafs are not wider then your current leafs.
    Leafs are about 1/4" thick, record your thickness as a point of reference.
    The thicker your donor leafs, the less leafs you will need to add.
    (A little steel goes a long way.)
    Take your tape measure with you to the yard.

    Research to find a local junkyard: ( no local yards near me)
    Let your fingers do the walking. Maybe call a few yards to see if the have suitable trucks with potential donors. Maybe even the golden donor Chevy S 10 flatbed 1 ton.

    get 2 chevy leaf spring packs from the junkyard
    (S-10 One ton flatbed springs are ideal )
    (making sure the arch on them are similar)
    (more arch, more lift. Less arch less lift. )

    Disassemble the new donor leaf packs:
    Tighten C-clamps near the centerpins to keep the springs compressed.
    Remove the centerpin.
    Remove the factory clamps with an angle grinder.
    Slowly decompress the springs.
    Select middle leafs from each set of donors.
    cut the 2 new top leafs 34" overall, 17" each way from centerpin hole.
    cut the 2 new bottom leafs 26" overall, 13" each way from centerpin hole.
    diamond cut ends approx 30 degree angles / \
    Clean up & preventative maintenance

    Items to purchase:
    Purchase new U-bolts.
    Purchase new center pins.
    Leaf pads, wheel borrow tire or bike inner tubes to cut to size. (Squeak relief)

    Build side clamps.
    ( http://www.tacomaworld.com/forum/suspension/220579-1-hour-spring-clamps.html )

    Repack your new leafs like (an Add-a-leaf) from top to the bottom: NON-TSB
    Bump stop
    Leave current main spring for proper length and bushings.
    Leave second leaf for current soft ride with minimal load.
    Add the new top leaf 34" overall with inner tube cut on top near ends.
    Add the new bottom leaf 26" overall with inner tube cut on top near ends.
    Leave overload leaf, if needed.
    Add new center pin, cut to fit bump stops with hacksaw.
    Add new U-bolts ( stock length plus thickness of 2 new leafs)
    Repeat on the other side.

    Add-a-leaf "how to" reference thread
    ( http://www.tacomaworld.com/forum/suspension/54186-aal-install-second-gen.html )
    ( http://www.tacomaworld.com/forum/suspension/31118-how-install-add-leaf-w-pics.html )

    Am I missing anything?

    rybern and 59ksmall like this.
  19. Jan 20, 2013 at 5:15 PM
    #1219
    4WD

    4WD [OP] cRaZy oLdmAn

    Joined:
    Jul 2, 2009
    Member:
    #19185
    Messages:
    23,530
    Gender:
    Male
    First Name:
    Doug
    Lakeside, Ca / Gardnerville, Nevada
    Vehicle:
    2004 DC TRD 4x
    Grey wire MOD, deck plate, diff breather MOD, 2nd gen. OME 883# on Tundra 5100's, OMD custom 3" leafsprings, rear shock relocation, Ivan Stewart TRD rims w/285/75/16's, '02 bumper MOD, Famous Fabrications sliders , LED interior/exterior lights, bed bar, Custom tube bumper, Old school KC day lighters,Red Ring 8" HID flood, Kenwood vhf 2M.. umm some other shit I'm forgetting right now
    You got all that shit in this thread ???:eek::eek::confused::notsure:

  20. Jan 20, 2013 at 5:59 PM
    #1220
    wareagle1

    wareagle1 Well-Known Member

    Joined:
    May 2, 2012
    Member:
    #78068
    Messages:
    458
    Gender:
    Male
    First Name:
    Brad
    Fayetteville, TN
    Vehicle:
    07 Tundra DC 5.7
    notta
    Sounds to me like you got it. Doug, did he miss anything?

Thread Status:
Not open for further replies.

Products Discussed in

To Top
